Applications: spike suppressors, magnetic amplifiers and so on.
Performance characteristics：
l Low Noise: When placed in front of the diode, they can suppress the noise which is caused by the change of the transient current change more effectively
l Low Loss: There is low hysteresis loss and almost no resistive loss through the components
l Diode Protection: The products suppress current and voltage spikes within the circuit, protecting the diode
l Space Savings: can be mounted directly onto the leads of diodes and no additional circuit board space required.
材料特性：
Saturation magnetic induction Bs（T） | 1.20 |
Coercivity Hc （A/m） | <1 |
Curie temperature Tc（℃） | 570 |
working temperature (℃) | -55～130 |
Maximum permeability μm | ＞100×104 |
Br/Bs（Static） | >85% |
